The PALEX ABC Dry Chemical Powder (Outer Cartridge) Fire Extinguisher – 25 KG is a heavy-duty trolley-mounted wheeled fire extinguisher designed for large-scale fire hazards involving Class A, Class B, Class C, and electrically initiated fires.
This extinguisher uses ABC Dry Chemical Powder (Mono Ammonium Phosphate) as the extinguishing medium and a 2 KG CO₂ outer gas cartridge as the propellant system. The wheeled design allows easy mobility across industrial sites, warehouses, fuel storage areas, manufacturing facilities, and other high-risk environments.
Manufactured in accordance with IS 16018:2012, this extinguisher delivers high fire ratings, extended discharge duration, and long-range firefighting capability for industrial fire protection.
Speak to our fire safety expert to learn more about this product.
| Parameter | Details |
|---|---|
| Manufacturer | Palladium Safety Solutions Pvt. Ltd. |
| Trade Mark / Brand | "PALEX" |
| BIS Standard Code | IS 16018:2012 |
| Type | Wheeled Fire Extinguisher – CO₂ Outer Cartridge Type |
| Parameter | Details |
|---|---|
| Capacity | 25 kg |
| Fire Rating | 20A, 233B |
| Fire Classes | Class A, B, C & Electrically Started Fires |
| Effective Discharge Time | Minimum 30 Seconds (Actual: Approx. 40 Seconds) |
| Discharge Range | Minimum 6 m (Actual: Approx. 6.5 m) |
| Percentage of Discharge | Minimum 85% (Actual: Approx. 93%) |
| Working Temperature | -30°C to +55°C |
| Service Pressure | 15 Bar |
| Maximum Service Pressure | 17 Bar |
| Component | Specification |
|---|---|
| Body | Mild Steel Sheet (Max. 0.25% Carbon, 0.05% Phosphorus, 0.05% Sulphur) |
| Extinguishing Media | Mono Ammonium Phosphate (50% / 90%) conforming to IS 4308:2019 |
| Neck Ring | MS Pipe (Filling Dia Ø 74 mm) |
| Cap | Brass |
| Discharge Hose | Rubber Braided EPDM Hose (Length: 4 m) |
| Discharge Nozzle | Brass |
| Syphon Tube (Inlet / Outlet) | MS Pipe |
| Gas Cartridge | 2 kg CO₂ Outer Gas Cartridge |
| Trolley Wheel | Solid Rubber Wheel |
| Carrying Handle | MS Pipe |
| Test | Specification |
|---|---|
| Hydrostatic Pressure Test | 35 Bar |
| Burst Pressure Test (Body) | 55 Bar |
| Burst Pressure Test (Discharge Hose) | Not Less Than 50 kgf/cm² |
| Parameter | Details |
|---|---|
| Diameter | 300 mm ± 2 mm |
| Height | 580 mm ± 2 mm (Without Wheel) |
| Cylinder Thickness | 3 mm Thick Sheet |
| Full / Gross Weight | Approx. 65–67 kg |
The extinguisher undergoes a 7-Tank Anti-Corrosion Treatment Process followed by an Epoxy Powder Coating.
| Parameter | Details |
|---|---|
| Inspection & Testing | As per Approved Quality Assurance Plan (QAP) |
| Finish | PO Red as per IS:5 (Shade 538) |
| Marking | As per IS 16018:2012 |
| Approvals | BIS (Bureau of Indian Standards) |
| Maintenance, Care & Refilling | As per IS 16018:2012 |
| Parameter | Details |
|---|---|
| Packing Type | Corrugated Paper or Suitable Jute Bags |
| Item | Quantity |
|---|---|
| Fire Extinguisher | 1 No. |
| Wheel Assembly | 3 Wheels |
| CO₂ Gas Cartridge | 1 No. (Mounted) |
Palladium Safety Solutions Pvt. Ltd.
An ISO 9001:2015 Certified Company
| Parameter | Details |
|---|---|
| Capacity | 25 kg |
| Fire Rating | 20A, 233B |
| Fire Classes | Class A, B, C & Electrically Started Fires |
| Effective Discharge Time | Minimum 30 Seconds (Actual: Approx. 40 Seconds) |
| Discharge Range | Minimum 6 m (Actual: Approx. 6.5 m) |
| Percentage of Discharge | Minimum 85% (Actual: Approx. 93%) |
| Working Temperature | -30°C to +55°C |
| Service Pressure | 15 Bar |
| Maximum Service Pressure | 17 Bar |
Drag to pan · Scroll or pinch to zoom · +/- buttons · Arrow keys to move
Could not display this PDF in the browser.
A 25KG ABC Dry Chemical Powder Fire Extinguisher is a trolley-mounted wheeled extinguisher designed to suppress Class A, Class B, Class C, and electrically initiated fires using Mono Ammonium Phosphate dry powder.
The extinguisher is suitable for:
An outer cartridge extinguisher uses a separate CO₂ gas cartridge mounted externally to pressurize and discharge the extinguishing agent when activated.
The 2KG CO₂ cartridge provides rapid pressurization, ensuring efficient discharge of the ABC dry powder during firefighting operations.
Yes. It is specifically designed for:
Yes. ABC dry powder is non-conductive and suitable for electrically initiated fires.
The trolley-mounted design allows easy transportation and deployment of a high-capacity extinguisher across large industrial sites.
Common applications include:
A trolley-mounted extinguisher offers:
A 25KG ABC extinguisher provides:
